Raman

MultiRAM is Bruker's stand-alone FT-Raman spectrometer, covering a spectral range of 3600-50 cm-1 (Stokes shift). At its core sits Bruker's patented interferometer with gold-coated optics and permanent RockSolid alignment, delivering the stability and throughput that demanding emission experiments such as Raman spectroscopy require. Because the interferometer alignment is permanent rather than user-adjustable, the instrument keeps its factory performance over years of routine use without recalibration.

Key features:

• Spectral range 3600-50 cm-1 (Stokes shift)

• Patented interferometer with gold-coated optics

• Permanent RockSolid alignment - no user realignment needed

• High stability and throughput for emission (Raman) experiments

• Stand-alone configuration - does not require an external FT-IR bench

Typical applications:

• Materials identification and characterisation by Raman spectroscopy

• Polymer and pharmaceutical raw material analysis

• Research applications requiring long-term measurement stability

Bruker BRAVO is a handheld Raman spectrometer built for fast raw material identification and verification with laboratory-grade spectrum quality. Its patented SSE (Sequentially Shifted Excitation) technology mitigates fluorescence, which is the main obstacle that normally prevents Raman-based raw material verification, while the DuoLaser design gives a broad spectral range across sample types. As a Class 1 laser device it carries no laser safety requirements, so it can be deployed on the shop floor without special controls, and the guided OPUS TOUCH interface with extensive library support keeps identification workflows accessible to non-specialist operators.

Key features:

• SSE (Sequentially Shifted Excitation) - patented fluorescence mitigation

• DuoLaser design for a broad spectral range

• Laser Class 1 - no laser safety requirements

• Intuitive OPUS TOUCH interface with guided verification and ID workflows

• IntelliTip automated measuring tip recognition

• WiFi and Ethernet connectivity with remote control like a benchtop instrument

• SyncService automated data transfer

• Built for pharma compliance (21 CFR Part 11, Data Integrity, USP, Ph. Eur.)

Typical applications:

• Raw material verification and unknown substance identification

• Incoming goods inspection in pharma and chemical manufacturing

• Field and shop-floor identification without laboratory infrastructure

Tornado, a Bruker company, is a global provider of chemical analysis and measurement systems built around process Raman spectroscopy. Raman is a highly selective, non-destructive optical technique that uses the inelastic scattering of laser light to probe molecular structure and generate detailed, molecule-specific spectral fingerprints, which makes it well suited to identifying and quantifying chemical species in complex mixtures. Because measurements can be taken directly through transparent containers or in-line with fiber-optic probes, Tornado's analyzers deliver continuous, real-time insight into reaction dynamics, material transformations and product quality without stopping the process to take a sample.

Key features:

• Proprietary optical technology built specifically for process Raman analysis

• Non-invasive, non-destructive measurement through transparent containers or fiber-optic probes

• Real-time monitoring for continuous process insight

• Highly selective, molecule-specific spectral identification

• Backed by Bruker's global chemical analysis portfolio

Typical applications:

• Real-time reaction monitoring in chemical and pharmaceutical manufacturing

• In-line quality assurance without process interruption

• Identification and quantification in complex mixtures

• Process control and manufacturing PAT applications
